Waterproof Switch
CAD $ 15.00
High quality waterproof stainless steel push button switch with red led back light. These are great for start/stop or for controlling bilge pump, blower, lights gauges etc. Switches mount with a 1.00″ hole and are held in place with the included bulkhead nut.
These switches work great in our Minijet Switch Panel
Description
Specifications:
Voltage: 12v
Load: 5A
Hole size 1”
Latching switch:
Push it = ON
Push it again = OFF
Contact Configuration: 1NO 1NC
Momentary switch:
Push & Hold = ON
Release = OFF
Contact Configuration: 1NO 1NC
Wiring:
Red/Black = LED light
Yellow = Normally closed
Blue = Normally open
Additional information
| Weight | 0.1 kg |
|---|---|
| Dimensions | 12 × 5 × 5 cm |
| Style | Latching, Momentary |
